High-speed doors – as standard with FU control
Hörmann high-speed doors are used both inside and as exterior doors to optimise the flow of traffic, improve room conditions and save energy. The Hörmann range includes both vertically and horizontally opening, transparent doors with a flexible curtain. They are also available in combination with sectional doors and rolling shutters, as well as with powerful, service-friendly spiral doors with smooth aluminium profiles.
Doors sometimes take up a large portion of commercial buildings. They thus offer substantial energy savings potential – for more information about the amortisation and retrofitting see the Hörmann energy savings compass.
Good reasons to try Hörmann high-speed doors
Safety as standard
Safety light grilles integrated into the side elements monitor the closing zone of the door leaf up to a height of 2500 mm. The safety light grilles ensure compliance with safety requirements in accordance with DIN EN 13241-1.This does away with the need for additional installations on the door (e.g. closing edge safety device, photocell). Profit from this high level of safety with a high-speed door that is exceptionally easy to fit and service.
Long service life and high efficiency as standard
The frequency converter control takes stress off the entire door mechanism, guaranteeing nearly wear-free, quiet door travel.The high opening and closing speeds optimise your operations and reduce heat losses. In addition, they relieve the entire door mechanism through the smooth starting and braking action which considerably extends the service life of the door. For heavy, insulated doors the door travel is supported by springs, and for high-speed sectional doors with H and V track applications by wear-free counter weights.
Efficient thermal insulation
Uniformly foamed steel sections
Hot-galvanized, double-skinned sections with PU rigid foam infill provide for particularly high thermal insulation, resulting in a UD value of 1.95 W/ (m²·K)*. The doors are supplied as standard in White aluminium (RAL 9006). The exterior is characterised by the fine Micrograin lines, on the interior the sections are Stucco-textured.
* For 25 m² door surface
Increased thermal insulation thanks to ThermoFrameWell-insulated high-speed doors are essential in heated halls. The ThermoFrame separates the side element from the building structure. The thermal break along with additional seals improves thermal insulation by up to 15 % and is easy and quick to fit. The ThermoFrame can be optionally ordered for doors with 42-mm and 67-mm-thick sections. It is already included in the scope of delivery for Iso Speed Cold 100 doors.
A permanently clear view
Duratec glazing guarantees maximum scratch resistance despite heavy use in rough industrial environments. The special surface coating protects the pane from scratches and damage caused by cleaning.For 67 mm insulated doors, you receive the aluminium glazing frame with thermal break with triple glazings. We deliver 42 mm insulated doors with double glazing.
With SmartControl, we can perform a technical analysis of your high-speed door control at any time. We can access the most important information regarding the error messages in real time via the online portal and often correct the error quickly. This way, you save costs thanks to fewer and shorter service calls and benefit from fewer or shorter downtimes, as wear parts can be replaced at an early stage.
Are you an architect and have questions about our products, or are currently in the planning phase and need information on model variants, combination options and custom designs? Or are you already designing a building and need technical support or details for the planned subsections? Benefit from our decades of experience: Our architecture consultants would be pleased to assist you.
